序號
Serial no |
部件名稱
Description |
規格型號
Model |
數量
Quantity |
|
1 |
機械型號
Model of equipment |
T320G1500-3 |
|
|
2 |
外型尺寸
Extemal dimensions(L*W*H) |
1520*1710*2300 |
|
|
3 |
磁筒（筒徑*工作磁系長度）
Magnetic tube(Dia*I of the working
magnetis system ) |
320*1500 |
1 |
|
4 |
磁輥（輥徑*工作磁系長度）
Magnetic roller(wore roll Dia*L of
the magnetic system ) |
150*1500 |
3 |
|
5 |
筒與輥轉速
Cylinder and the roller speed |
35r/min-356r/min |
|
|
6 |
筒表面磁場強度
Cylinder surface magnetic field |
大于3000GS
Strength＞3000GS |
|
|
7 |
輥表面磁場強度
Roller surface magnetic field |
大于13000GS
Strength＞3000GS |
|
|
8 |
分選粒度
Separating particle size |
0~3MM |
|
|
9 |
處理能力
Capacity |
5-8t/h |
|
|
10 |
電機功率
Motor power |
2.2Kw |
3 |
|
11 |
輥筒刷
Roller brush |
|
3 |
|
12 |
工作電壓
Operating voltage |
380V |
|
